PSI Audio - A21-M Speaker
  • PSI Audio - A21-M Speaker

PSI Audio - A21-M Speaker

A21-M – Perfectly accurate mid field monitor.

The A21-M high power near / mid-field precision monitor covers a broad frequency spectrum, allowing the user to be in full control of their audio production. Its unique and highly optimised assets make it perfect for near, mid-field and surround sound applications where ultimate precision is required.

The powerful bi-amplified output stages features the unique “AOI” output stages and has a protection circuit, which can be monitored via the red LED on the front panel.
The active crossover, with integrated “CPR”, gives the A21-M unprecedented impulse behavior – with excellent stereo imaging. The crossover is also optimized for maximum phase coherence, projecting a wide horizontal and vertical ideal listening area.

The electronics are housed in a unit mechanically isolated from the speaker cabinet to avoid resonance at high sound pressure levels.

It comes in Red or Black color.  To learn more about this amazing product, please Click here .

Read more

Send Enquiry on PSI Audio - A21-M Speaker

Thank you for your enquiry. We will get back to you as soon as possible.

Send Enquiry on PSI Audio - A21-M Speaker

* denotes required fields.

Overview

Product Key Features

  • Very high SPL in a compact cabinet.
  • Flat frequency response.
  • Optimised directivity by phase coherency.
  • Class G low temperature amplifier stage.
  • Compatible with industry standard mouting systems.
  • Amplifier unit acoustically uncoupled from speaker cabinet.
  • Protection circuits with overload indicator.
  • Real balanced input.
  • Designed for stereo and multichannel monitoring.
  • Magnetically shielded for use close to video monitors.
  • AOI Technology.
  • ALG Technology.
  • CPR Technology.
  • PSC Technology.

        General Specs

        • Power RMS: 120 + 50W
        • Program Power: 170W
        • Input Impedance: Sym, 10k Ohms
        • Sensitivity for 100 dB @ 1m: 0.775 V
        • Signal to Noise Ratio: 96 dBA
        • Continuous Max SPL@1m: 108 dB (single)
        • Input Overload: 24 Vpp
        • Program Max SPL@1m: 119 dB (pair)
        • Response at -6dB: 38 - 23000 Hz
        • Tolerances: ±2 dB (44Hz - 20kHz)
        • Distortion THD: less than 1.4% (90Hz-12kHz)
        • Phase tolerances: ±45° (190Hz - 20kHz)
        • Dispersion (P.N. 4 - 16 kHz) at -6 dB: 90° x 90° (H x V)
        • System: 2 Way(s)
        • Crossover frequency: 2.4 kHz
        • Woofer's dim. Ext. / Diaphragm: Ø217 mm / Ø170 mm
        • Tweeter's dim. Ext. / Diaphragm: Ø100 mm / Ø25 mm
        • Connectors: 1 x XLR F / 3P
        • Signal input: 1=GND, 2=(+), 3=(-)
        • Material: MDF
        • Dimensions W x H x D mm: 250 x 400 x 300
        • Gross / Net Weight: 14.5 / 13.2 kg
        • Voltage: 115/230V (50-60Hz)
        • Consumption Standby-Quiescent-Max: 1.2 - 5 - 150 W
        • Mean / Max Humidity: less than 75% / less than 90%
        • External Temperature: 5 - 40°C
